กล้องถ่ายภาพความร้อนวัดไข้ CEM DT-980ํํY High Performance Thermal Imaging Camera, Design for 2019-nCOV Wuhan New Corona Virus Epidemic Situation,Temperature Range 32°C to 42°C, Accuracy ±0.5°C,HDMI Port
DT-980Y CEM : High Performance Thermal Imagers Thermometer ยี่ห้อ CEM
กล้องตรวจจับอุณหภูมิร่างกาย คัดกรองคนมีไข้ด้วยกล้องถ่ายภาพความร้อน Thermal Imager Human body Temperature CEM DT-980Y กล้องถ่ายภาพความร้อน
DT-980Y CEM กล้องถ่ายภาพความร้อน High Performance Thermal Imager ภาพความร้อน แสดงผลบนหน้าจอ LCD สามารถบันทึกลงในการ์ด Micro SD Card, สามารถเชื่อมต่อคอมพิวเตอร์ ผ่านสาย USB โอนข้อมูลภาพถ่ายไปยังเครื่องคอมพิวเตอร์ได้ CEM DT-980Y Thermal Imager สามารถบันทึกวิดีโอพร้อมเสียง
High Performance Thermal Imagers Human body Temperature
The DT-980Y is a rapid screening Thermal Imager for measuring surface temperatures. With 20 ms fast thermal imaging, non-contact testing is easier and helps in improving the detection efficiency as well as assist on protection by prevention.
It automatically tracks the highest/lowest temperatures and easily finds the abnormal temperature in the detection area.
The external large display terminals make on-site monitoring much easier. Transfer data online to the free Thermview+ App and use the powerful analysis software.
With an 80x80pixels resolution, 32x continuous digital zoom and the patented AUF thermal imaging, the DT-980Y is the ultimate tool in detection and prevention of diseases like the COVID-19 Coronavirus.
Features:
- High Resolution IR Images : (80×80) Infrared resolution
- Visible Light Digital Camera : 5 Megapixels Digital camera resolution with flash provides sharp images regardless of lighting conditions
- Picture in Picture : Displays thermal image super-imposed over a digital image
- LED Flashlight : Allows the visual camera and fusion to be used in poorly lit environments
- Wide Temperature Range : From -20 to +350°C targeting electrical and industrial applications ±2% Accuracy reliable temperature measurement
- Thumbnail view : Easy to view and analyze images quickly
- Audio recorded with the video image : A speaker to listen to audio recorded with the video image
- Li-Ion Rechargable Battery: Lasts >4hrs continuous use; replaceable
- HDMI : HDMI High resolution video output
- Inside 100M Memory : About 80pictures or one minute video record
- Copy to USB : Easy uploads images from camera to USB memory card
- Area (Min/Max) Mode : Shows the Minumum or the Maximum Temperature reading in the selected area
- EMC
- EN: 61326-1 EN: 61010-1
- Laser Sighting : To aim at the target
- Dimensions (H x W x D): 224 x 77 x 96 mm
- Weight: 500g
DT-980Y CEM กล้องถ่ายภาพความร้อน
![]() |
![]() |
Application:
- Fast and Accurate temperature measurements for surface temperatures
- Specially designed for human temperatuer detection
- Settable alarm for high temperature
- Quick large scale temperature scanning
- Higher saftey as can be used from a safe distance
-
Easily connected to external large display
DT-980Y CEM กล้องถ่ายภาพความร้อน
Specifications:
Imaging and optical data | |
IR resolution | 80×80 pixels |
Focal Plane Array (FPA) / Spectral range | Uncooled microbolometer / 8–14 µm |
Focal length | 9mm |
Field of View (FOV) | 17°x17° |
Minimum focus distance | 0.1m |
Spatial resolution (IFOV) | 3.78mrad |
Thermal sensitivity/NETD | < 0.1°C @ +30°C (+86°F)/ 100mK |
Image frequency | 50Hz |
Focus Mode | Manual |
Zoom | 1-32x continuous, digital zoom |
Image presentation | |
Display | 2.8 in. LCD, 240 × 320 pixels |
Image modes | IR image, Visual image, Image Fusion |
Picture in Picture | IR area on visual image |
Color palettes | Iron/rainbow/grey/grey inverted |
Measurement | |
Object temperature range | Filter mode: 32°C to 42°C |
-20°C to +150°C (-4°F to +302°F) 0°C to +350°C (+32°F to +662°F) |
|
Accuracy | ±0.5°C in 32°C to 42°C ±2°C (±3.6°F) or ±2% of reading (Environment temperature 10°C-35°C object temperature > 0°C. ) |
Measurement analysis | |
Spot | Center Spot |
Automatic hot /cold detection | Auto hot or cold markers |
Emissivity correction | Variable from 0.01 to 1.0 |
Measurement corrections | Emissivity, Reflected temperature |
Set-up | |
laser | < class2 |
Set-up commands | Local adaptation of units, language, date and time formats, information of camera |
Language selection | English, Chinese, French, German, Spanish |
Storage of videos/images | |
Inside Memory | 100M bytes, About 80pictures or one minute video record |
Storage media | 8Gbytes Micro SD card |
Video storage format | Standard MPEG-4, 1280×960@30fps, on memory card > 60 minutes |
Image storage format | Standard JPEG, including measurement data, on memory card > 6000 pictures |
Digital camera | |
Built-in visible light digital camera | 5 Megapixels |
Built-in digital lens data | FOV 59° |
Data communication interfaces | |
Interfaces | USB-mini, audio, HDMI |
Video out | HDMI |
USB | Data & Live video transform between camera and PC or smartphone |
Power system | |
Battery / Input voltage | Li-ion battery, 4 hours operating time / DC 5V |
Charging system / Power management | In camera (AC adapter) /Automatic shutdown |
Environmental data | |
Operating temperature range | -15°C to +50°C (5°F to +122°F) |
Storage temperature range | – 40°C to +70°C (- 40°F to +158°F) |
Drop test | 2m |
Bump | 25g(IEC60068-2-29) |
Vibration | 2g(IEC60068-2-6) |
Physical data | |
Camera weight, incl. battery | <500g |
Camera size (L × W × H) | 224x77x96 |
CEM DT-980Y Rapid Human Thermal Scanning
Accessories:
-
Infrared camera with lens, Earphone(Optional), Battery, software CD-ROM, wrist strap, micro SD card, Adaptor, USB cable & HDMI cable (Optional), Gift box.
- Tripod stand (Not include)
