AC แคลมป์มิเตอร์ 200A Mini AC Clamp Meter + NCV Detector รุ่น MA150

AC แคลมป์มิเตอร์ 200A Mini AC Clamp Meter + NCV Detector ยี่ห้อ Extech, USA

SKU: EXTECH MA150 Category:

Description

แคลมป์มิเตอร์  เครื่องวัดกระแสไฟฟ้า AC Clamp-on Meter > Clamp meter

MA150: 200A Mini AC Clamp Meter + NCV Detector ยี่ห้อ Extech, USA

Compact size AC Clamp meter with built-in AC Voltage detector and Flashlight

This mini clamp-on meter offers the convenience of a built-in non-contact AC voltage detector and bright white LED flashlight. Measures AC current up to 200 Amp with 0.1 Amp resolution. Also measures AC/DC Voltage and Resistance. The 0.7 in. jaw fits around conductors up to 300MCM. Compact size allows getting into tight spaces. Auto power off, data hold, and low battery indicator. Includes two AAA batteries and case.

Built-in white LED flashlight + Built-in AC non-contact Voltage (NCV) detector

Features:

  • 0.7″ (18mm) jaw opening
  • 2000 count backlit LCD display
  • Non-contact AC Voltage detector (100 to 600VAC) via clamp tip
  • Built-in white LED flashlight
  • Continuity and Diode Test, Max Hold, Auto power off

For complete specs please download the product datasheet (not available for some accessories)

Specifications:

Unit
(เปรียนเทียบ)
AC/DC แคลมป์มิเตอร์ 200A AC/DC Mini Clamp Meter+Voltage Detector รุ่น MA120
รุ่น MA120
AC แคลมป์มิเตอร์ 200A Mini AC Clamp Meter + NCV Detector รุ่น MA150
รุ่น MA150
 AC Current
Max Resolution
Accuracy
200A
100mA
±3.0%
200A
100mA
±2.5%
 DC Current
Max Resolution
Accuracy
 200A
0.1A
±3%
 AC Voltage
Max Resolution
Non-contact Non-contact/600V
0.1mV
 DC Voltage
Max Resolution
600V
0.1mV
 Resistance
Max Resolution
Accuracy
20MΩ
0.1Ω
±3.0%
 Frequency
Max Resolution
1kHz
0.01Hz
 Dimensions  7×2.5×1.3″ (178x65x32mm)  7×2.5×1.3″ (178x65x32mm)
 Weight  6 oz (170g)     6 oz (170g)
CE NIST CATII 600V warranty12
หมายเหตุ ::
• ราคาสินค้ารวม ยังไม่รวมภาษีมูลค่าเพิ่ม 7%
• ราคาสินค้าไม่รวมค่าขนส่ง
• สเปคและราคาสินค้าอาจมีการเปลี่ยนแปลงโดยไม่แจ้งให้ทราบล่วงหน้า

measuring instruments  Download Brochure ดาวโหลดโบร์ชัวร์สินค้า
