แคลมป์มิเตอร์ เครื่องวัดกระแสไฟฟ้า Clamp-on Meter > AC/DC Clamp meter
AC/DC Clamp-on meter with built-in dual Thermocouple inputs and Non-contact Voltage Detector
EX613: 400A Dual Input AC/DC Clamp Meter + NCV ยี่ห้อ Extech, USA
AC/DC Clamp-on meter with built-in dual Thermocouple inputs and Non-contact Voltage Detector
The EX613 is a 400 Amp dual input AC/DC Clamp meter with built in non-contact voltage detector. This TRMS AC/DC Clamp Meter has dual thermocouple inputs for T1, T2, T1-T2 Differential Temperature measurements. This DMM measures AC/DC Voltage and Current, Resistance, Capacitance, and Frequency. Additional features include: DC micro-amp function for flame rod measurements, Diode open circuit voltage of 2.8 Volt, Data Hold plus fast Peak Hold for capturing current surges at motor startup, and capacitance measurement to 40mF. The EX613 displays 40,000 counts on its LCD screen and is built in a rugged double molded housing. Comes complete with test leads, 9V battery, 2 Type K bead wire Temperature probes, and carrying case.
Features:
- True RMS measurements for accurate AC Voltage and Current measurements
- Dual type K thermocouple input with Differential Temperature function (T1, T2, T1-T2)
- Built-in non-contact IR Thermometer with laser pointer for locating hot spots (up to 518°F/270°C)
- Built-in non-contact Voltage detector with LED alert
- DC µA multimeter function for HVAC flame rod Current measurements
- Data Hold plus fast Peak Hold of current surges during motor startup
- 40,000 count multimeter functions for DC Voltage, Resistance, Capacitance, and Frequency for high resolution over wider ranges
- Measures motor capacitors to 40,000µF
- 1.25″ (32mm) jaw opening for conductors up to 500MCM
- Rugged double molded housing
- Auto power off with audible alert and disable function
- Autoranging with manual override
- 8 to 1 distance to target ratio
- Complete with CAT III-600V, double molded test leads, 9V battery, two general purpose Type K bead wire probes and case
EX600 Series Common Features:
- True RMS measurements for accurate AC Voltage and Current measurements
- Dual type K thermocouple input with Differential Temperature function (T1, T2, T1-T2)
- Built-in non-contact IR Thermometer with laser pointer for locating hot spots (up to 518°F/270°C)
- Built-in non-contact Voltage detector with LED alert
- DC µA multimeter function for HVAC flame rod Current measurements
- Data Hold plus fast Peak Hold of current surges during motor startup
- 40,000 count multimeter functions for DC Voltage, Resistance, Capacitance, and Frequency for high resolution over wider ranges
- Measures motor capacitors to 40,000µF
- 1.25″ (32mm) jaw opening for conductors up to 500MCM
- Rugged double molded housing
- Auto power off with audible alert and disable function
- Autoranging with manual override
- 8 to 1 distance to target ratio
- Complete with CAT III-600V, double molded test leads, 9V battery, two Type K bead wire probes and case
EX613 and EX623 Additional Feature
|
EX622 and EX623 Additional Feature
|
• DC Current function ideal for automotive,
heavy equipment and marine applications |
• Built-in non-contact IR Thermometer
with laser pointer for locating hot spots • 8 to 1 distance to target ratio |
Comparisons: Extech 600 Series Clam Meter
![]() |
|||
Specifications | EX613 | EX623 | |
Temperature (IR)
|
—
|
-58 to 518°F (-50 to 270°C)
|
|
AC Current | 400.0A | 400.0A | |
DC Current |
400.0A
|
400.0A | |
Max resolution | 10mA | 10mA | |
Basic ACA accuracy | ±1.5% | ±1.5% | |
AC/DC Voltage (Max Res.) | 600V (0.1mV)/600V (0.01mV) | 600V (0.1mV)/600V (0.01mV) | |
DC μA Current | 4000μA (0.01μA) | 4000μA (0.01μA) | |
Resistance (Max Res.) | 40.000MΩ (0.01) | 40.000MΩ (0.01Ω) | |
Capacitance (Max Res.) | 10pF to 40,000μF (0.01nF) | 10pF to 40,000μF (0.01nF) | |
Frequency (Max Res.) | 40MHz (0.001Hz) | 40MHz (0.001Hz) | |
Temperature (Type K) | -58 to 1832°F (-50 to 1000°C) | -58 to 1832°F (-50 to 1000°C) | |
Diode Test | < 2.8V | < 2.8V | |
Duty Cycle | 0.5 to 99.0% | 0.5 to 99.0% | |
Dimensions | 9×3.1×1.9″ (229x80x49mm) | ||
Weight | 10.7 oz (303g) |
