แคลมป์มิเตอร์ > เครื่องวัดกระแสไฟฟ้า Clamp-on Meter > AC / DC Clamp meter

380947: 400A True RMS AC/DC Mini Clamp Meter ยี่ห้อ Extech, USA

True RMS mini-clamp with high current resolution

The compact Extech 380947 is a 400 Amp True RMS mini clamp meter. This meter has a small diameter jaw designed to reach in small areas while providing 1mA resolution and very low-current sensitivity. This mini clamp meter is useful for current and frequency related troubleshooting in plant maintenance, electrical, HVAC, and telecom work, as well as home electrical, fleet maintenance, marine, and motorcycle repairs. Comes with battery and manual.

Features:

Three models provide high Accuracy and Resolution
Large 4000 count LCD display with full function indication
Fast 40 segment analog bargraph
One touch “Auto Zero” for DCA measurements eliminates the need to turn a knob to zero adjust
Data hold, Max/Min recall display
0.9″ (23mm) clamp jaw opening
Overload protection to 400A DC
True RMS models recommended for measurements where distortion may otherwise cause inaccuracies
Optional 3-prong AC Line Separator enables safe and easy measurements on power cables with molded plugs (splits hot conductor from neutral and ground)

Specifications:

Unit (เปรียบเทียบ)	รุ่น 380942	รุ่น 380941	รุ่น 380947
True RMS	True RMS	—	True RMS
AC Current: Resolution Accuracy	30A 0.1mA ±(2.0%+5d)@50/60Hz	200A 100mA ±(1.0% +2d)	4A/40A/100A/400A 1mA/10mA/100mA/100mA ±(1.5% +3d)
DC Current: Resolution Accuracy	30A 1mA —	40A 10mA ±(1.0% +2d)	40A/400A 10mA/100mA ±(1.0% +2d)
AC Voltage: Resolution Accuracy	400V 0.1V ±(2.0%+5d)	400V 0.1V ±(1.5% +4d) (50/60Hz)	—
DC Voltage: Resolution Accuracy	400V 0.1V ±(1.0%+2d)	400V 0.1V ±(1.0% +2d)	—
Resistance: Resolution Accuracy	—	400Ω 0.1Ω ±(1.5% +2d)	—
Frequency: Resolution Accuracy	—	10kHz 0.01Hz ±(0.5% +2d)	10kHz 0.01Hz ±(0.5% +2d)
Resolution
Dimensions:	7.2×2.5×1.4″ (183x64x36mm)	7×1.75×1.25″ (178x45x32mm)	7.2×2.5×1.4″ (183x64x36mm)
Weight:	6.2 oz (190g)	6 oz (170g)	6.2 oz (190g)

Ordering Information:
380942…………..True RMS 30A Mini Clamp Meter
380942-NIST….380942 with Certificate of Calibration Traceable to NIST
380941…………..200 Amp DC/AC Mini Clamp DMM
380941-NIST….380941 with Certificate of Calibration Traceable to NIST
380947…………..True RMS DC/AC Mini Clamp Meter
380947-NIST….380947 with Certificate of Calibration Traceable to NISTAccessories:
480172…………..AC Line Separator – 3 prong
