Description

แคลมป์มิเตอร์ เครื่องวัดกระแสไฟฟ้า Clamp-on Meter > AC/DC Clamp meter

380926: 2000A True RMS AC/DC Clamp Meter ยี่ห้อ Extech, USA

Full range MultiMeter functions with high resolution to 0.1µA/0.1mV

The 380926 is a category IV, 2000-Amp, TRMS AC/DC Clamp Meter which has a rugged 2 in. jaw that accommodates two 500MCM cables. A built-in full-function DMM can measure AC/DC Voltage and Current, Resistance, capacitance, frequency, Duty Cycle, Diode and Continuity. Measurements are displayed on the large 4000 count backlit display for easy viewing in dimly lit areas. Additional features include DCA push button zero, Data Hold, and Relative function. Complete with test leads and 9V battery.

Features:

Full function autoranging DMM includes
AC/DC Voltage and Current, Resistance, Capacitance, Frequency, Duty Cycle, Diode and Continuity
Current measurements to 2000A through the clamp and 400mA via test leads
Large 4000 count backlit display for high resolution and easy viewing in dimly lit areas
Basic DCV accuracy of 1% with 0.1mV resolution and current resolution to 0.1μA
Rugged 2″ (50mm) jaws accomodate one 2000MCM or two 500MCM cables
Features include DCA push button zero, Relative measurements and Data Hold
Heavy duty ABS case with built-in stand and thumb control function switch
Complete with test leads and 9V battery

Specifications:

Unit	Ranges	Max. Resolution	Basic Accuracy (%rdg+digits)
DC/AC Current (Clamp):	400A, 2000A	0.1A	±(2% + 5d)
DC/AC Current (DMM):	400μA, 4000μA, 40mA, 400mA	0.1μA	±(1.2% + 5d)
DC Voltage:	400mV, 4.0V, 40V, 400V, 1000V	0.1mV	±(1% + 2d)
AC Voltage:	4V, 40V, 400V, 1000V	1mV	±(1.2% + 5d)
Capacitance:	50nF, 500nF, 5.0μF, 50μF	10pF	±(3% + 5d)
Resistance:	400Ω, 4.0kΩ, 40kΩ, 400kΩ, 4MΩ, 40MΩ	0.1Ω	±(1% + 5d)
Frequency:	5Hz, 50Hz, 500Hz, 5kHz, 50kHz, 100kHz	0.01Hz	±(1% + 5d)
Duty Cycle:	1% to 99%	0.1%	±(1% + 5d)
Diode Check:	Yes
Continuity:	Yes
Dimensions/Weight:	10 x 2.9 x 1.5″ (255x73x38mm) / 14oz. (380g)

Ordering Information:
380926…………….2000A True RMS DC/AC Clamp/DMM
380926-NIST……2000A True RMS DC/AC Clamp/DMM w/Calibration Traceable to NIST
TL805………………Spare Set of CAT. III-1000V Test Leads
CA899………………Large soft case with shoulder strap

หมายเหตุ ::
• ราคาสินค้ารวม ยังไม่รวมภาษีมูลค่าเพิ่ม 7%
• ราคาสินค้าไม่รวมค่าขนส่ง
• สเปคและราคาสินค้าอาจมีการเปลี่ยนแปลงโดยไม่แจ้งให้ทราบล่วงหน้า
