สวิตชิ่งเพาเวอร์ซัพพลาย 160W Switching Power Supply รุ่น DCP42

สวิตชิ่งเพาเวอร์ซัพพลาย Switching Power Supply แรงดัน 0 to 42V, กระแส 0 to 10A ขนาด 160W ยี่ห้อ Extech, USA

รหัสสินค้า: EXTECH DCP42 หมวดหมู่:

รายละเอียด

สวิทช์ชิ่ง เพาเวอร์ซัพพลาย Switching Power Supply ขนาด 160W

DCP42: 160W Switching Power Supply ยี่ห้อ Extech, USA

Single Output Continuous Switching Power Supply with USB

DCP42 is a 160W Switching Power Supply. Single Output Continuous Switching Power Supply with USB offers high efficiency electrical power conversion for greater energy conservation and lighter weight. Complete with power cord, software, and USB cable. Software includes DC ramp and waveform generator.
Features:
  • Constantly calculates and adjusts the Voltage and Current limit points according to available maximum power (160W)
  • At maximum current (10A), voltage is limited to 16V
  • At maximum voltage (42V), current is limited to 3.8A
  • Dual action rotary encoder control with push knob for fine and coarse tuning
  • Remote control for Programming, Output Voltage/Current, and ON/OFF using supplied software, driver, and USB
  • Three on-board user-defined Voltage/Current presets
  • Store 20 presets with up to 999 cycles each on a PC via USB and supplied Software
  • Software also includes DC Ramp and Waveform Generator
  • Complete with power cord, software, and USB cable

For complete specs please download the product datasheet (not available for some accessories)

Specifications:
 Output Voltage  0 to 42V
 Output Current  0 to 10A
 Basic Accuracy  ±(0.2%+5 counts)
 Load Voltage Regulation  ≤0.15% (10-100% rated current)
 Line Voltage Regulation  ≤0.02% (90-264V AC)
 Load Current Regulation  ≤0.5% (10-90% rated voltage)
 Line Current regulation  ≤0.1% (90-264V AC)
 Ripple and Noise  ≤5m Vrms, ≤50m Vp-p
 Dimensions  7.9 x 3.7 x 9.5” (200 x 95 x 245mm)
 Weight  5lbs (2.3kg)
Accessories:
• Complete with power cord, software, and USB cable
CE  warranty12
