เครื่องวัดความสั่นสะเทือน Vibration Meter รุ่น AR63A

฿12,000.00

Vibration Meter เครื่องวัดแรงสั่นสะเทือน เครื่องวัดความสั่นสะเทือน, แรงสั่นสะเทือน 3 Parameters : Displacement: 0.001~1.999mm, Acceleration: 0.1~199.9m/s², Velocity: 0.1~199.9mm/s ยี่ห้อ Smart Sensor

รหัสสินค้า: AR63A หมวดหมู่:

รายละเอียด

เครื่องวัดความสั่นสะเทือน > Vibration Meter เครื่องวัดความสั่นสะเทือน รุ่น AR63A

เครื่องมือวัดความสั่นสะเทือน สำหรับใช้ในการตรวจวัดความสั่นสะเทือนของเครื่องจักร เพื่อตรวจหาสาเหตุหรือแนวโน้ม ที่จะเกิดความเสียหาย เพื่อเป็นแนวทางในการวางแผนงานซ่อมบำรุงได้อย่างมีประสิทธิภาพ

AR63A : Vibration Pen Meter เครื่องวัดความสั่นสะเทือน ยี่ห้อ Smart Sensor®

Vibration Meter เครื่องวัดความสั่นสะเทือน รุ่น AR-63A

Vibration meter is used for measuring periodic motion, to check the imbalance and deflecting of moving machinery. Specifically designed for present measuring various mechanical vibration. So as to provide the data for the quality control, run time and equipment upkeep.

Features:

  • Measuring range: 1.0~300mm(steel)
  • Sound velocity range: 1000~9999m/s
  • Application for measuring the thickness of metal, plastic, ceramic, glass motor, electric fan, pump, air compressor, machine tools etc.
  • 10 thickness measurement storage and recall function
  • Auto linear compensation
  • Auto calibration to assure the accuracy.
  • Coupling status indication
  • Alarm setup
  • Auto/Manual power shut off
  • Large LCD display with backlight
  • Low battery indication
Specification:
 Measuring Range  Acceleration:0.1-199.9m/s² peak(rms*v2)
 Velosity:0.1-199.9mm/s rms
 Displacement:0.001-1.999mm p-p(rms*2v2)
 Accuracy  ±5%±2digits
 Frequency Response  Acceleration:10Hz-1KHz(LO) 1KHz-15KHz(HI)
Velosity/Displacement:10Hz-1KHz
 LCD display  3½ digits display
 Data Output  AC Output 2V Peak,Load
 Test Mode  Acceleration/Velocity/Displacement
 Sampling Rate  1S
 Low Battery Indication  7 seconds
 Auto Power Shut Off  Turns off automatically after 60 seconds
 Power  9V Battery(6F22)
 Battery Life  Continue Using for 20 hours
 Dimensions  183x67x30mm (7.2×2.64×1.18 inch)
 Weight  147g / 0.33lb
Accessories:
  •  AR63A Meter, with Calibration Certificate, manual, 9V batteries, carry case.
CE
หมายเหตุ ::
• ราคาสินค้ารวม ยังไม่รวมภาษีมูลค่าเพิ่ม 7%
• ราคาสินค้าไม่รวมค่าขนส่ง
• สเปคและราคาสินค้าอาจมีการเปลี่ยนแปลงโดยไม่แจ้งให้ทราบล่วงหน้า

measuring instruments

Download ดาวน์โหลดไฟล์ข้อมูลสินค้า
PDF  AR63A Brochure ( 0KB )
PDF  AR63A Instruction Manual ( 0KB )
