เครื่องวัดความหนาสี Coating Thickness Gauge meter รุ่น CM8801FN

฿5,800.00

Coating Thickness Gauge meter เครื่องวัดความหนาสี, Range: 0 – 1250μm, 0 – 49mil ยี่ห้อ Nicety

รหัสสินค้า: CM8801FN หมวดหมู่:

รายละเอียด

Thickness meter เครื่องวัดความหนา > Coating Thickness Gauge  meter เครื่องวัดความหนา รุ่น CM8801FN Range: 0 – 1250μm, 0 – 49mils

2 in 1 type combines two probes in one meter and automatically identify the substrate materials.Depending on the substrate, the symbol Fe or NFe is displayed on the screen.

CM8801FN : Coating Thickness Tester ยี่ห้อ Nicety

2 in 1 วัดความหนาสีบนวัสดุแบบ Ferrous และ Non-Ferrous

คุณสมบัติ:

    • หน้าจอขนาด 4 digits, 10mm
    • ช่วงวัด 0 -1250 μm / 0 – 49mils
    • ความละเอียด 0.1 μm ที่ช่วงวัด 0 – 99.9 μm และ 1 μm ที่ช่วงวัดเกิน 100μm
    • ความเที่ยงตรง +/- 2.0μm
    • บันทึกค่าการวัดได้ 10 ข้อมูล
    • แบตเตอรี่ขนาด AAA จำนวน 2 ก้อน
Features:
  • Includes F type (CM8801F), and F/NF 2 in 1 type (CM-8801FN)
  • Microcomputer based, auto-detection of the probe type, no damage to the coating surface
  • The screen is the biggest available, Flip display
  • Final 10 measurements memory
  • Comes with a portable clip for your belt
  • Metric/imperial system selectable: auto power off
  • Fe type is applicable for nonmagnetic coatings on ferromagnetic substrates, e.g., zinc, chromium, copper, tin, or paint, plastics, enamel on iron or steel.
  • A symbol Fe is displayed on the screen.
  • NFe type is applicable for electrically non-conductive coatings on non-ferrous metals, e.g., paint, enamel, or plastics on aluminum, brass, or zinc and anodic coating on aluminum.A symbol NFe is displayed on the screen.
  • 2 in 1 type combines two probes in one meter and automatically identify the substrate materials.Depending on the substrate, the symbol Fe or NFe is displayed on the screen.
Specifications:
 Range  0 – 1250μm, 0 – 49mils
 Resolution  0.1μm/0.1mils
 Accuracy  0.3 mils +3% or ±2.0μm +3%
 Modes  Single & Continuous
 Battery Indicator  low battery indicator
 Metric/ Imperial  Convertible
 Dimensions  119 x 52 x 28 mm.
 Weight  40g
Accessories:
  • Substrate blocks (steel x 1pc, Aluminum x 1pc), Calibration foils, User’s manual.

CE

หมายเหตุ ::
• ราคาสินค้ารวม ยังไม่รวมภาษีมูลค่าเพิ่ม 7%
• ราคาสินค้าไม่รวมค่าขนส่ง
• สเปคและราคาสินค้าอาจมีการเปลี่ยนแปลงโดยไม่แจ้งให้ทราบล่วงหน้า


measuring instrumentsProduct Description: Coating Thickness Gauge
Model: CM8801F,CM8801N,CM8801FN.

Advantage:
Includes F type (CM-8801F), NF type (CM-8801N) and F/NF 2 in 1 type (CM-8801FN)
* Has CE marking, conforms with the essential health and safety equirements set out by the European Directives
* The F type probe for measuring the thickness of non-magnetic coating on Ferromagnetic base (e.g. iron, nickel and more), like plating layer, lacquer layer, porcelain enamel layer, phosphide layer, copper/aluminum and some ally tiles papers and others.
* The NF type probe for measuring the thickness of any non-magnetic coating on Non-Ferromagnetic metal base (aluminum, brass, stainless steel, etc.), like anodizing, varnish, paint, enamel, plastic coating, power layers, and others.
* Microcomputer based, auto-detection, no damage to the coating surface.
* Metric/imperial system selectable, Auto power off.
* 10 points value memory.
* Flip LCD display
* Suitable for the laboratory, Powder Coating Companies, Manufacturing Companies, Paint Suppliers, Manufacturing Companies, Steel and Aluminum Refinishing, Automobile Dealers, Auto Auctions, Body Shops, Auto Detailers and any company needing a highly accurate measurement of the dry coating thickness and can be used even in harsh field conditions.
